MCCB 32A 4-Pole – Industrial Grade Circuit Breaker (MG 100L-0032-04)

This 32A 4-Pole MCCB (Molded Case Circuit Breaker) provides reliable protection for low-voltage electrical systems in industrial, commercial, and large-scale residential applications. Designed to safeguard against overloads and short circuits, it ensures safe and stable operation in 3-phase power distribution networks. Built with a durable flame-retardant casing and compliant with IEC/EN 60947-2 standards, this MCCB is ideal for critical applications requiring dependable performance and easy maintenance.

Features:

• Rated Current (In): 32A
• Poles: 4
• Rated Insulation Voltage (Ui): 800V
• Impulse Withstand Voltage (Uimp): 8kV
• Rated Operational Voltage (Ue): 400/415V
• Rated Ultimate Short-Circuit Breaking Capacity (Icu): 18kA
• Rated Service Short-Circuit Breaking Capacity(Ics): 18kA
• Rated Short-Time Withstand Current (Ii): 400A
• Frequency: 50/60Hz
• Material: Flame-retardant casing
• Operating Temperature: -5°C to +40°C
• Compliance Standard: IEC/EN 60947-2
• Warranty: 1 Year

Applications:

• Industrial systems – for machinery and panel protection
• Commercial buildings – for load distribution and safety
• Renewable energy systems – for solar and wind power control
• Large residential complexes – for 3-phase incoming power protection
• Backup power systems – for generator and UPS integration
